Engineered once, deployable many times.

An expandable healthcare container is a medical-grade clinical facility built inside an ISO-compatible expandable shell, combining the transport economics of a sea container with the clinical performance of a fixed medical suite. structmod expandable healthcare containers are configured as primary-care clinics, operating theatres, ICU pods, imaging suites, laboratories or specialty units — each configuration validated through structmod's biomedical engineering workflow to meet IEC 60364-7-710 medical electrical requirements, infection-control zoning per HBN or equivalent national guidance, and destination-country ministry-of-health standards.

The clinical envelope differs from the standard expandable container in several ways. Interior finishes use medical-grade seamless vinyl or epoxy flooring with coved skirtings for infection control. Walls carry antimicrobial surfaces or hygienic PVC cladding. HVAC delivers HEPA H13 filtration to clinical zones, with pressure cascades between clean and dirty areas. Medical gases — O2, N2O, medical air, vacuum — reticulate to wall-mounted terminal units per ISO 9170. The pop-out zones are engineered to the same clinical standard as the fixed zones, so the full 75 m² deployed area is usable clinical space.

structmod expandable healthcare containers ship to health ministries, NGOs running field outreach campaigns, oil & gas operators servicing remote workforces, mining camp operators, event medical support contractors, and specialty healthcare providers running mobile screening programmes. Lead time is 10-14 weeks from contract signature; configuration to specific clinical brief adds 2-4 weeks to the standard expandable container timeline. Full medical equipment integration is available as a structmod-supplied option or compatible with client-sourced equipment.

Tipik Konuşlanma Sırası

1. Gün 0 — ISO konteyner kamyonla gelir, forklift veya yayıcıyla boşaltılır
2. Gün 0 — krikolar açıldı, tesviye doğrulandı
3. Gün 0 — hidrolik duvarlar çalışma alanına açıldı
4. Gün 0–1 — altyapı bağlantıları ve iç ekipman yapılandırması
5. Gün 1 — FAT protokolüne göre devreye alma ve işlevsel test
6. Gün 1 — İ&B belgesiyle kullanıcı eğitimi ve teslimat

Spec sheet — STR-3138

Tam çizimler, hesap notları, DoP, İ&B kılavuzu ve FAT raporu her ünite ile dahildir. Özellikler gösterge niteliğindedir — proje gereksinimlerine göre yapılandırılabilir.
